Acmer · Diode laser
Acmer P1 10W
Simple open diode laser with 10 W and a large work area. Very affordable, but accessories for clean cutting cost extra.
Ideal for: Beginners who mainly engrave and only cut thin material.
Open device: You need laser safety glasses for the matching wavelength while working, and so do onlookers. More at Laser safety.
Price in the manufacturer's shop€209, 10 WAs of 26 Oct 2026, can change dailyThere is no manufacturer's shop price for your region, the EU price is shown.
Pros and cons
Pros
- 40 x 41 cm work area for around €209
- Tilt sensor, emergency stop and child lock as standard
- IR module can be retrofitted for metal marking
Cons
- only 10 W, air assist and camera cost extra
- Cutting data not assigned to power
- open frame without enclosure and extraction
Specs
| Price range | under €500 |
|---|---|
| Price in the manufacturer's shop | €209, 10 W (As of 26 Oct 2026) |
| Laser type | Diode laser |
| Laser source | Diode 450 nm (±5 nm), 10 W optical; 20 W version currently not available, 1064 nm IR module can be retrofitted |
| Power (optical, main source) | 10 W |
| Work area | 400 × 410 mm |
| Dimensions | 615 × 587 × 210 mm |
| Weight | 5.8 kg |
| Construction type | Gantry |
| Enclosure | open |
| Laser class | Class 4 (derived, manufacturer does not state a class) |
| Speed (max.) | 167 mm/s (10,000 mm/min) |
| Cutting according to the manufacturer | Manufacturer's parameter table for the 10 W module: board up to 7.5 mm at 100 % and 120 mm/min, acrylic up to 4 mm at 100 % and 70 mm/min, passes not stated; shop states, without power rating, up to 25 mm wood, 15 mm dark acrylic, 8 mm MDF |
| Air Assist | optional (C4 air pump) |
| Camera | optional (A500 LightBurn camera) |
| Fume extraction | no, open frame; enclosure optional |
| Rotary attachment | optional (M2 rotary roller) |
| Software | Acmer Studio, Acmer App, LightBurn, LaserGRBL |
| Connectivity | Wi-Fi (app), TF card |
| Materials (according to the manufacturer) | Wood, Plywood, MDF, Paper, Leather, Acrylic (opaque) |
Source: Manufacturer or retailer specifications, As of 10/2026. Cutting figures are manufacturer values under ideal conditions.
