xTool · Combination machine
xTool X1
First impression from Nadin (2 days of testing on site, test unit) I spent two days at the regional shop in Gedern (Hesse), which as an xTool host already has the X1 on site, and tried it out there together with Sascha and Katharina: Katharina operated the device, I watched and helped test. It was a test model, not a production unit, and the software was still in beta. My honest first impression: the X1 is not intuitive, and the instructions are rather poor. That may be partly down to the beta software. Above all, the module change with calibration and the question of which laser suits which job with which settings were not self-explanatory. A module change took us about 8 to 10 minutes, the calibration afterwards around 30 minutes. Having to test and experiment with a laser is normal. But using only the presets from the software, I did not get good results everywhere after two days: the device does not take the manual work off your hands. When engraving a coin with a 3D depth effect (depth map), the device often showed a defocus error. We measured 73 dB at 1 m distance, while engraving a coin with the AP2 air purifier on its highest setting. There was only a slight smell in the room with acrylic, none at all with wood and metal. The frame consists of just three die-cast parts and arrives fully assembled.
The X1 can be viewed in advance with xTool hosts, for example at the regional shop in Gedern (Hesse). Book a demo (no affiliate link)
Enclosed 55 W CO₂ laser with a flying galvo head (20 W diode) and swappable modules for UV, MOPA and fibre. Pre-sale since 12.10.2026, shipping from 29.10.2026.
Ideal for: Small businesses and ambitious makers who cut and engrave with CO₂ and want to add glass and metal later without buying a second device.
Price in the manufacturer's shop€3,369 (was €3,669), Single CO₂Introductory price; CO₂ + diode galvo €3,959 (was €4,259); modules: 30 W fibre €1,979, 5 W UV €2,969, 60 W MOPA €3,169; presale with €100 deposit until 29.10.2026, balance payment and shipping from 29.10.2026As of 12 Oct 2026, can change dailyThere is no manufacturer's shop price for your region, the EU price is shown.
In a video by NadinMacht
The video is only loaded from YouTube when you click. Data is transmitted to Google in the process. More
Pros and cons
Pros
- 55 W CO₂ for cutting and 20 W diode galvo for fast engraving in one machine
- Galvo area of 615 x 320 mm, much larger than typical galvo lasers
- can be expanded later with UV, MOPA and fibre (laser swap)
- Pass-through (AutoPassthrough) for workpieces up to 299 cm long
- several lasers can be combined in one job, e.g. engrave with diode and cut with CO₂, without touching the workpiece
Cons
- 60 kg, two people needed to set it up; with laser module at the back (backpack) around 74 cm deep, with the lid open around 90 cm high
- Galvo and expansions only with the variant including the diode module (€3,959), each further module costs €1,979 to €3,169
- No fume extraction included, according to xTool the air purifier costs about €1,000 extra; operation, module changes and calibration were not very intuitive in the first test
Specs
| Price range | €3,000 to €5,000 |
|---|---|
| Price in the manufacturer's shop | €3,369 (was €3,669), Single CO₂; Introductory price; CO₂ + diode galvo €3,959 (was €4,259); modules: 30 W fibre €1,979, 5 W UV €2,969, 60 W MOPA €3,169; presale with €100 deposit until 29.10.2026, balance payment and shipping from 29.10.2026 (As of 12 Oct 2026) |
| Laser type | Combination machine |
| Laser source | CO₂ laser 55 W; diode galvo module 20 W (depending on variant, includes the galvo); optional UV 5 W (355 nm), MOPA 60 W and fibre 30 W (1,064 nm each), the modules use the galvo of the diode module |
| Power (optical, main source) | 55 W |
| Work area | 615 × 320 mm |
| Dimensions | 1000 × 580 × 420 mm |
| Weight | 60 kg |
| Construction type | Gantry and galvo |
| Enclosure | enclosed |
| Laser class | Class 1 when the device is closed (according to the manufacturer, FDA certified); class 4 when operated open (according to xTool) |
| Speed (max.) | CO₂ 600 mm/s; galvo (diode, UV, MOPA, fibre) 6,000 mm/s |
| Cutting according to the manufacturer | up to 18 mm basswood and 20 mm acrylic (CO₂, manufacturer's statement); workpieces up to 150 mm high (CO₂) or 140 mm (galvo), with pass-through up to 299 cm long (CO₂ only, with conveyor max. 68.9 mm material height according to xTool) |
| Air Assist | yes, integrated (according to xTool, information given during the test) |
| Camera | yes, triple camera system: 8 MP wide-angle, 12 MP close-up camera and height measurement camera; camera and point laser positioning, autofocus, LiDAR measuring system; close-up camera positioning accuracy under 0.3 mm in the centre, under 0.5 mm across the whole area; additional flame detection camera (according to Gipfelholz) |
| Fume extraction | not included; air purifier SafetyPro AP2 / AP2 Max (about €1,000 extra according to xTool) or inline fan IF2 compatible |
| Rotary attachment | optional (RA3), round engraving up to 110 mm diameter |
| Software | xTool Studio (Android, iOS, iPadOS, Windows, macOS); AImake compatible; LightBurn: not specified by the manufacturer |
| Connectivity | USB, Wi-Fi; file formats SVG, DXF, JPG, JPEG, PNG, BMP, TIF |
| Materials (according to the manufacturer) | Wood, Acrylic, Leather, Paper, Textiles, Plastic, Rubber, Silicone, Ceramic, Glass (engraving; internal engraving only with UV module, at a refractive index of 1.54 up to 600 x 300 mm in the upper 50 mm, 60 x 300 mm at 50 to 100 mm depth), Metal (painted/coated with diode, bare metal with fibre or MOPA module; metal embossing up to 415 x 225 mm with extraction hood) |
Further manufacturer information
| Work area for surface engraving | 615 × 320 mm |
|---|---|
| Work area for internal glass engraving (UV) | at a refractive index of 1.54: 600 × 300 mm in the top 50 mm, 60 × 300 mm at 50 to 100 mm depth |
| Metal embossing work area | 415 × 225 mm (with extraction hood for embossing) |
| Laser spot size | CO₂ 55 W: 0.175 × 0.175 mm; diode 20 W: 0.16 × 0.14 mm to 0.225 × 0.22 mm; UV 5 W: 0.017 × 0.017 mm; fibre 30 W: 0.05 × 0.05 mm; MOPA 60 W: 0.04 × 0.04 mm |
| Positioning accuracy | Close-range camera: below 0.3 mm in the centre, below 0.5 mm across the whole work area; wide-angle camera: below 0.5 mm in the central 50%, below 1 mm in the central 70%, below 2 mm across the whole work area |
| Measurement accuracy | ±0.5 mm; LiDAR measuring system with 0.01 mm machining accuracy |
| Camera resolution | 1,000 DPI |
| Motion accuracy | 0,015 mm |
| Preview | Snapshot preview via smartphone |
| Pre-assembled | yes |
| Max. power consumption | CO₂ 550 W; diode 65 W; UV and fibre 192 W; MOPA 300 W |
| Power adapter | 100 to 240 V AC, 50/60 Hz |
| Operating temperature | Main unit 0 to 35 °C; CO₂ and diode 0 to 35 °C; UV 10 to 35 °C |
| Storage temperature | Main unit −10 to 60 °C; laser module 0 to 35 °C |
Source: Manufacturer or retailer specifications, As of 10/2026. Cutting figures are manufacturer values under ideal conditions.
